Mecline Shoulder Support for ML 210, ML 510, ML 710 ML210, ML510 & ML710 Trigger Guns

Specifications
• Inlet: 1/4" Male
• Size: 13" L x 5.5” W
• Weight: 9.0 oz

Mecline ML 710 High Pressure Trigger Gun. This 9,280 PSI rated trigger gun comes with 3/8 F inlet x 3/8 F outlet

Specifications
• Permissible Pressure: 10,150 PSI
• Rated Pressure: 9,280 PSI
• Rated Flow Rate: 16.0 GPM
• Rated Temperature: 250° F
• Inlet: 3/8" Female
• Outlet: 3/8" Female
• Weight: 30.0 oz

Mecline L70 48” High Pressure Stainless Steel 3/8” Lance with Handle. This 9,280 PSI rated stainless steel lance comes with a vented grip and 1/4 F NPT outlet

Specifications
• Length: 48.0”
• Permissible Pressure: 10,150 PSI
• Rated Pressure: 9,280 PSI
• Rated Flow Rate: 16.0 GPM
• Rated Temperature: 320° F
• Inlet: 3/8" Male
• Outlet: 1/4" Female NPT (nozzle holder)
• Weight: 64.0 oz

Mecline VHP70-700 Stainless Steel AISI 303 Unloader Valve 10,150 PSI. With working pressures up to 9,280 PSI and flows up to 21.0 GPM

Featuring:
• Positioning of all O-Ring seals before the threads, for greater mechanical strength
• New shutter axially guided, for greater stability at high flow rates
• Stainless Steel seat and shutter of new shape, designed by fluid dynamics study to eliminateinstabilities and turbulences with great benefit in terms of long life.
• Stem with new internal anti-rotation system, for greater life
• Stem O-Ring seal Ø 3,53 (0.14”) is placed fixed on the connecting stem guide to allow the stroke of the Stainless Steel stem on O-Ring, increasing the life
• Maximum pressure safety lock.
• Minimum and Maximum pressure regulation lock

Specifications:
• Spring Color: Black
• Rated Pressure: 9,280 PSI
• Permissible Pressure: 10,150 PSI
• Rated Temperature: 194° F
• Rated Flow Rate: 21.0 GPM
• Material: All metallic parts are in stainless steel AISI 303
• Inlet Port: 1/2" F NPT
• Outlet Port: 1/2” F NPT
• Bypass Port: 1/2” F NPT
• Gauge Port: 1/4" F NPT
• Weight: 75.84 Oz
