Mecline ML 710 High Pressure Trigger Gun. This 9,280 PSI rated trigger gun comes with 3/8 F inlet x 3/8 F outlet

Specifications
• Permissible Pressure: 10,150 PSI
• Rated Pressure: 9,280 PSI
• Rated Flow Rate: 16.0 GPM
• Rated Temperature: 250° F
• Inlet: 3/8" Female
• Outlet: 3/8" Female
• Weight: 30.0 oz

Mecline Shoulder Support for ML 210, ML 510, ML 710 ML210, ML510 & ML710 Trigger Guns

Specifications
• Inlet: 1/4" Male
• Size: 13" L x 5.5” W
• Weight: 9.0 oz

General Pump 0° x #3.0 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 0°
• Nozzle Size: 3.0
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Mecline VHP70-700 Stainless Steel AISI 303 Unloader Valve 10,150 PSI. With working pressures up to 9,280 PSI and flows up to 21.0 GPM

Featuring:
• Positioning of all O-Ring seals before the threads, for greater mechanical strength
• New shutter axially guided, for greater stability at high flow rates
• Stainless Steel seat and shutter of new shape, designed by fluid dynamics study to eliminateinstabilities and turbulences with great benefit in terms of long life.
• Stem with new internal anti-rotation system, for greater life
• Stem O-Ring seal Ø 3,53 (0.14”) is placed fixed on the connecting stem guide to allow the stroke of the Stainless Steel stem on O-Ring, increasing the life
• Maximum pressure safety lock.
• Minimum and Maximum pressure regulation lock

Specifications:
• Spring Color: Black
• Rated Pressure: 9,280 PSI
• Permissible Pressure: 10,150 PSI
• Rated Temperature: 194° F
• Rated Flow Rate: 21.0 GPM
• Material: All metallic parts are in stainless steel AISI 303
• Inlet Port: 1/2" F NPT
• Outlet Port: 1/2” F NPT
• Bypass Port: 1/2” F NPT
• Gauge Port: 1/4" F NPT
• Weight: 75.84 Oz
