Accutek® QD-BISOBN4-4F 1/4 Nipple x 1/4 Female Pipe ISO Series B 7241-1 Brass 3,500 PSI Quick Disconnect. Fairview's ISO B Interchange Couplers Interchange with Aeroquip FD45, Foster FHK, Parker 60, Safeway BS10 and Faster HNV Series

Features:
• High flow characteristics and pressure ratings superior to Parker 60 series
• Industry interchangeability with other manufacturer's ISO "B" couplers and nipples
• Poppet style double shut-off.
• Nitrile NBR seals with PTFE back-up ring
• Proven ball lock mechanism
• 4 : 1 safety factor (Min. Burst = WP. X 4)
• Ideal for use with hydraulic and other fluids in both stationary and mobile industrial applications

Specifications:
• Working Pressure: 3,500 PSI
• Body Size: 1/4
• Female Pipe: 1/4
• Body Material: Brass
• Approx. Weight: 0.09 lbs

General Pump 40° x #9.0 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 40°
• Nozzle Size: 9.0
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Accutek® QD-BISOBC4-4F 1/4 Coupler x 1/4 Female Pipe ISO Series B 7241-1 Brass 3,500 PSI Quick Disconnect. Fairview's ISO B Interchange Couplers Interchange with Aeroquip FD45, Foster FHK, Parker 60, Safeway BS10 and Faster HNV Series

Features:
• High flow characteristics and pressure ratings superior to Parker 60 series
• Industry interchangeability with other manufacturer's ISO "B" couplers and nipples
• Poppet style double shut-off.
• Nitrile NBR seals with PTFE back-up ring
• Proven ball lock mechanism
• 4 : 1 safety factor (Min. Burst = WP. X 4)
• Ideal for use with hydraulic and other fluids in both stationary and mobile industrial applications

Specifications:
• Working Pressure: 3,500 PSI
• Body Size: 1/4
• Female Pipe: 1/4
• Body Material: Brass
• Approx. Weight: 0.30 lbs

General Pump 100438 Capillary Style 86° - 195° Adjustable Thermostat. Probe Style Thermostat Insulated SS Capillary Copper Immersion Bulb (UL/CSA approved), 16(4)A-380V Electric Rating

Features:
• Panel mounted, dual scale knob.
• Rapid response, ± 5° F
• 60 Inch capillary tube with bulb rated to 4,000 PSI
• UL/CSA approved

Specifications Sheet

Specifications:
• Temp Range: 86°- 195º F
• Max. Pressure: 4,000 PSI
• Electrical Rating AC: 120VAC-20A, 240VAC-20A, 120/240VAC-1/4HP
• Sensing Element: Copper Bulb
• UL/CSA Approved: Yes
• Weight: 0.40 Lb
