General Pump 65° #40.0 Q-Style Brass Soap (Black) Nozzle. General Pump offers a complete range of chemical nozzles. These nozzles have been designed and manufactured with the same exacting standards as the high pressure tips

Features
• Made in the USA
• Brass body
• Large color coded tip protector on Q-type nozzles permits rapid identification

Specifications
• Tip Angle: 65°
• Nozzle Size: 40.0
• Color Code: Black
• Style: Q
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

General Pump 40° x #4.0 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 40°
• Nozzle Size: 4.0
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Accutek® S1022-C Steel Male Hex Nipple 3/8 Male Pipe x 3/8 Male Pipe Hydraulic Fitting. Fairview's SAE steel pipe fittings create a stress-generated seal.

Specifications:
• Applications - Water, Oil, Air
• Working Pressure: 4,000 PSI
• Burst Pressure: 16,000 PSI
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.09 lbs

Features
• For use when high and low pressures are needed
• For example, spraying cleaning agents with low pressure through an injector valve and then cleaning with high pressure

Specifications
• Max Pressure: 4,000 PSI
• Max Flow: 8.0 GPM
• Max Temp: 195° F.
• Inlet: 1/4" Female NPT
• Outlets (2): 1/4" Female NPT
• Weight: 6.1 oz.
• Note: Requires one 1/4” MPT spray nozzle and one 1/4” MPT soap nozzle, which are not included
