Features
• High Quality, German engineered components
• Forged stainless steel housing, piston, and malleable seat
• Special heat and chemical resistant seals

Specifications
• Max Pressure: 8,700 PSI
• Max Flow: 21.0 GPM
• Max Temp: 300° F.
• Inlet: 1/2" Female NPT
• Outlet: 1/2" Female NPT
• Weight: 2.58 lb

PA VB 85/310 Rv and General YUB21405 blue spring trapped pressure unloader valve. At gun closure, the waterflow is discharged in bypass reducing the pressure in the system upstream of the valve

Featuring:
• Dynamic seals made up of O-ring and Back-up ring
• Optimized internal passages that guarantee reduced pressure loss
• Anti-rotation device of the piston positioned inside the valve and obtained by an hexagonal sector of the piston itself
• O-rings of the fittings positioned upstream to the thread : no risk of fittings ejected in case of overpressure
• Double feed connection
• Suitable for recycled water and strong detergents

Data Sheet

Specifications:
• Spring Color: Blue
• Permissible Pressure: 4,500 PSI
• Rated Pressure: 4,050 PSI
• Rated Flow Rate: 21.0 GPM
• Rated Temperature: 195° F
• Inlet Ports (2): 1/2" NPT F
• Outlet Port: 1/2” NPT F
• Bypass Port: 1/2” NPT F
• Replaces: 60.0485.65, VB 85/280, 60.0400.65, VB 80/280 and YUB2140
• Weight: 40.63 Oz
