Fimco Industries ATVBK-3025-QR. The FIMCO Boomless Nozzle ATV Boom Kit converts Spot Sprayers into a time saving liquid application tool. The boomless nozzle distributes 36 feet of total spray coverage with Xtender end tips and center spray tip offering increased capacity with precise liquid application. Each Nozzle sprays independently offering increased flexibility. Kit includes quick release mounting brackets. Our FIMCO exclusive manifold places pressure control and boom operation conveniently at your fingertips to fine tune your spray pattern

Features:
• Features FIMCOs exclusive quick release mounting system allowing you to quickly remove, change or store your spraying boom
• FIMCO exclusive manifold places pressure control at your finger tips
• Stainless steel 3 nozzle wetboom with broadcast tips delivers 36 Feet of total spray coverage with Hypro tips that can be turned on and off independently
• Tubular stainless steel construction provides strength and durability
• Xtender spray tips and singular center spray tip plus drip free shut off valves

Specifications:
• Warranty: 1 yr Consumer / 90 day Commercial
• Boom Spray Coverage 3.8 GPM Pump (ft.): 30
• Boom Spray Coverage 4.5 GPM Pump (ft.): 36
• Minimum Pump Size (GPM): 3.8
• Note: Does Not Include ATV, Straps, Tank & Pump
• Sprayer Weight: 18 lbs

Delavan PowerFLO™ 7812 I-Series 2.1 GPM 60 PSI Diaphragm Pump with 3/8” FNPT Ports. Demand Switch – Operates only when liquid flow is required

Features:
• 100% Factory tested
• 2 Year warranty from date of purchase

Motor:
• Type: 12 VDC permanent magnet, totally enclosed, non-ventilated
• Leads: 14 AWG, 6” long with 2-pin connector
• Max Amps: 8.5
• Duty Cycle: See Heat Rise graph

Materials of Construction:
• Motor Shell: Coated Steel
• Housing: Polypropylene
• Valves: Santoprene
• Diaphragm: Santoprene
• Fasteners: Zinc plated

Pump:
• Demand Switch – Operates only when liquid flow is required
• Type: 3-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 140°F Max.
• Priming Capabilities: 14’
• Max. Flow: 2.1 GPM
• Pressure Shut-Off: 60 PSI
• Inlet/Outlet Ports: 3/8” FNPT
• Packaging: Small box
• Weight: 6.0 lbs

Delavan PowerFLO™ 5850 Series 5.0 GPM 45 PSI Diaphragm Pump. Demand Switch – Operates only when liquid flow is required.

Features:
• Certified to NSF/ANSI Standard 61 & 372
• Made in the USA
• 100% Factory tested
• 2 Year warranty from date of purchase

Motor:
• Type: 12 VDC permanent magnet, totally enclosed, non-ventilated
• Leads: 14 AWG, 6” long with 2-pin connector
• Amps: 6.0 – 16
• Duty Cycle: See Heat Rise graph

Materials of Construction:
• Motor Shell: Coated Steel
• Housing: Polypropylene
• Valves: Viton
• Diaphragm: Santoprene
• Fasteners: Stainless Steel

NSF/ANSI Certified:
• NSF/ANSI Standard 61 - Drinking Water System Components - Health Effects
• NSF/ANSI 372 and conforms with the lead content requirements for “lead free” plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act

Pump:
• Demand Switch – Operates only when liquid flow is required
• Type: 5-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 140° F Max.
• Priming Capabilities: 14’
• Max. Flow: 5.0 GPM
• Pressure Shut-Off: 45 PSI
• Inlet/Outlet Ports: 1/2” FNPT
• Packaging: Small box
• Weight: 6.0 lbs
