General Pump 40° (White) #4.5 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 40° (White)
• Nozzle Size: 4.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General Pump 25° (Green) #4.5 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 25° (Green)
• Nozzle Size: 4.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

• Triplex Plunger Pump
• Solid Shaft for Belt or Gear Drive
• Max. Volume: 5.5 GPM
• Max. Discharge Pressure: 5,000 PSI
• Max. Pump Speed: 1750 RPM
• Shaft Diameter: 24mm Solid
• Max. Horsepower Requirements: 17.0 BHP
• Bearings are premium SKF tapered roller bearings that provide extra load support, smoother and lower crankcase running temperatures and overall extended pump life
• Max. Fluid Temp.: 160 degrees F.
• Inlet Ports (2): 1/2" FPT
• Discharge Ports (2): 3/8" FPT
• Drive Side: Standard right
• Forged brass head & valve covers
• Plungers are extra thick solid ceramic titanium impregnated for extended seal and pump life
• Weight: 35.0 lb.

• Triplex Plunger Pump
• Solid Shaft for Belt or Gear Drive
• Max. Volume: 4.0 GPM
• Max. Discharge Pressure: 4,000 PSI
• Max. Pump Speed: 1750 RPM
• Shaft Diameter: 24mm Solid
• Max. Horsepower Requirements: 11.0 BHP
• Bearings are premium SKF tapered roller bearings that provide extra load support, smoother and lower crankcase running temperatures and overall extended pump life
• Max. Fluid Temp.: 160 degrees F.
• Inlet Ports (2): 3/4" BSP
• Discharge Ports (2): 3/8" BSP
• Drive Side: Standard right
• Forged brass head & valve covers
• Plungers are extra thick solid ceramic titanium impregnated for extended seal and pump life
• Weight: 34.0 lb.
