General Pump D10001 Quick Disconnect Coupler Socket Brass 1/4” x 1/4" NPT-F 5,000 PSI

Features:
• Quick disconnect design
• Brass
• EPDM O-Ring

Specifications:
• Quick Disconnect Coupler: Socket
• Body Material: Brass
• Socket Size: 1/4"
• Thread: 1/4” NPT-F
• Max Temp: 175°
• Max Operating Pressure: 5,000 PSI
• Replaces QCS1FB
• Weight: 0.15 lb

Comet Seal Kit, Water TW 22mm

Rteplaces Comet # 5019.0646.00

Delavan PowerFLO™ 2200 Series Diaphragm Pump. Demand Switch – Operates only when liquid flow is required

Motor:
• Type: 12 VDC, permanent magnet, thermally protected, splash proof
• Leads: 18 AWG, 4.5” long with 2-pin connector
• Amps: 3.5 Max.
• Duty Cycle: Intermittent

Materials of Construction:
• Motor Housing: Nylon 6/6
• Pump Housing: Polypropylene
• Valves: Viton
• Diaphragm: Santoprene

Pump:
• Demand Switch – Operates only when liquid flow is required
• Shut-Off: 40 ±5 PSI factory setting
• Turn-On: 25 ±5 PSI factory setting
• Type: 2-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 110°F Max.
• Priming Capabilities: 4 feet suction lift
• Max. Flow: 1.0 GPM
• Max Pressure: 40 PSI
• Inlet/Outlet Ports: 3/8” hose barb
• Packaging: Small box
• UPC: 830344009724 & 830344007591
• Weight: 1.25 lbs

ProPulse, a Schieffer Company, backed by more than 90 years of innovation

Features:
• Assembled in USA with high quality components
• Suitable for commercial pressure cleaning applications
• Rubber construction throughout
• Reinforcement: One layer of high tensile braided steel – R1 Rating
• Cover: Wrapped finish with embossed lay line
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 50’
• Working (Maximum): Up to 4,000 PSI
• Burst (Minimum): 12,000 PSI
• Color: Black
• Maximum Temperature: 250° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Permanent heavy duty black bend restrictors on both ends
• Weight 9.5 lbs
