Mecline VHP51 Unloader Valve 8,000 PSI. With working pressures up to 7,250 PSI and flows up to 26.4 GPM, the VHP51 can continuously handle water up to 160° F (up to 194° F for short periods)

Featuring:
• Positioning of all o-rings before the threads, giving greater mechanical strength
• Ease of maintenance: the whole regulating unit can be totally removed from on top
• The locking ring nut has a set screw for a safer pressure setting
• A nickel-plated brass body, granting greater resistance to corrosion and overall wear
• All internal parts in stainless steel, including the outlet fitting and piston cylinder
• Internal safety lock to avoid overpressure
• Suitable for wall mount

Specifications:
• Rated Pressure: 7,250 PSI
• Permissible Pressure: 8,000 PSI
• Rated Temperature: 194° F
• Rated Flow Rate: 26.4 GPM
• Material: Chemically nickel-plated brass body. Internal parts in Stainless steel including fittings
• Inlet Port: 1/2" F
• Outlet Port: 1/2” F
• Bypass Port: 1/2”
• Replaces VHP50-500
• Weight: 40.57 Oz
