Beckett 5270001U ADC Powerlight 12 VDC Burner Igniter with cad cell (electronic eye). Beckett’s new PowerLight igniters offer improved performance and longer life. This igniter is easy to install and is designed as a universal replacement in Beckett and other manufacturer’s burners

Application Information:
• External heat sink eliminated for improved performance and reduced frequency of replacement due to overheating and arcing
• Easy change to interrupted ignition to increase igniter life and save energy
• Lightweight, single piece design is compatible with Beckett and other burners to reduce required inventory
• Fully potted with improved epoxy to withstand thermal shock and protect electronic components; waterproof
• Simplified wiring requirements and fewer wires for ease of installation

PRODUCT SHEET

Specifications:
• Input Voltage: 10.8 - 16 Vdc
• Output Voltage: 20kV peak
• Output Current: 25 mA
• RMS Input Current: 2.5 A Maximum
• Ambient Operating Temperature: -40°F (-40°C) to 150°F (66°C)
• Storage Temperature: -40°F (-40°C) to 150°F (66°C)
• Moisture: 5 to 95% Relative Humidity
• Replaces Beckett #’s 5218301U, 51776U & 51777U
• Weight: 2.05 lbs

General Pump D11009 Quick Disconnect Coupler Plug Hardened Steel Zinc Plated 3/8” x 3/8" NPT-M 4,000 PSI

Features:
• Quick disconnect design
• Hardened Steel Zinc Plated

Specifications:
• Quick Disconnect Coupler: Plug
• Body Material: Hardened Steel
• Plug Size: 3/8"
• Thread: 3/8” NPT-M
• Max Temp: 175°
• Max Operating Pressure: 4,000 PSI
• Replaces QCP2MS
• Weight: 0.10 lb

Beckett 5270002U SDC Powerlight 12 VDC Burner Igniter with cad cell (electronic eye). Beckett’s new PowerLight igniters offer improved performance and longer life. This igniter is easy to install and is designed as a universal replacement in Beckett and other manufacturer’s burners

Application Information:
• External heat sink eliminated for improved performance and reduced frequency of replacement due to overheating and arcing
• Easy change to interrupted ignition to increase igniter life and save energy
• Lightweight, single piece design is compatible with Beckett and other burners to reduce required inventory
• Fully potted with improved epoxy to withstand thermal shock and protect electronic components; waterproof
• Simplified wiring requirements and fewer wires for ease of installation

PRODUCT SHEET

Specifications:
• Input Voltage: 10.8 - 16 Vdc
• Output Voltage: 20kV peak
• Output Current: 25 mA
• RMS Input Current: 2.5 A Maximum
• Ambient Operating Temperature: -40°F (-40°C) to 150°F (66°C)
• Storage Temperature: -40°F (-40°C) to 150°F (66°C)
• Moisture: 5 to 95% Relative Humidity
• Replaces Beckett #’s 5218303U & 51779U
• Weight: 2.14 lbs

Features:
• Automatic trigger shutoff and trigger lock

Specifications:
• Max Pressure: 4,000 PSI
• Max Flow: 7.0 GPM
• Max Temp: 300° F.
• Inlet: 3/8" Female NPT
• Outlet: 1/4" Female NPT
• Weight: 18 oz
