Fairview Screw for Installing Brackets Onto GAS-FLO® Propane Regulators

Fairview GAS-FLO™ CP-2412 1/4” OD x 12” Short Nose POL x 1/4 MPT Copper Propane Gas Pigtail. Fairview's Short POL To 1/4 MPT Copper pigtails are ideal for use with Propane Gas

Applications:
• Propane gas copper pigtails and hogtails provide a flexible connection between the container valve and the regulator
• Solder connections Copper tube for PIGTAILS is 1/4" O.D. by .049 WALL
• Usage depends on application and requirements
• With soldered ends and a wide selection of connections and lengths

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Tube OD: 1/4”
• Approx. Length: 12”
• Tube Material: Copper
• End: Short Nose P.O.L
• End: 1/4 MPT
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.30 lbs

Fairview GAS-FLO™ CP-2620 1/4” OD x 20” Long Nose POL (7/8 Hex nut) x 1/4 Swivel Male Inverted Flare Copper Propane Gas Pigtail. Fairview's Long POL To 1/4 Inverted Flare Copper pigtails are ideal for use with Propane Gas

Applications:
• Propane gas copper pigtails and hogtails provide a flexible connection between the container valve and the regulator
• Solder connections Copper tube for PIGTAILS is 1/4" O.D. by .049 WALL
• Usage depends on application and requirements
• With soldered ends and a wide selection of connections and lengths

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Tube OD: 1/4”
• Approx. Length: 20”
• Tube Material: Copper
• End: Long Nose P.O.L (7/8 Hex nut)
• End: 1/4 Swivel Male Inverted Flare
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.40 lbs

Fairview 122-C 3/8 MPT x 3/8 MPT Brass Hex Nipple. Fairview's Hex Nipple Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.07 lbs
