Fairview Screw for Installing Brackets Onto GAS-FLO® Propane Regulators

Fairview GAS-FLO® RV Style U Mounting Bracket

Fairview GAS-FLO™ CP-2412 1/4” OD x 12” Short Nose POL x 1/4 MPT Copper Propane Gas Pigtail. Fairview's Short POL To 1/4 MPT Copper pigtails are ideal for use with Propane Gas

Applications:
• Propane gas copper pigtails and hogtails provide a flexible connection between the container valve and the regulator
• Solder connections Copper tube for PIGTAILS is 1/4" O.D. by .049 WALL
• Usage depends on application and requirements
• With soldered ends and a wide selection of connections and lengths

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Tube OD: 1/4”
• Approx. Length: 12”
• Tube Material: Copper
• End: Short Nose P.O.L
• End: 1/4 MPT
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.30 lbs

Fairview GAS-FLO™ 1/4” ID x 12” AOL Type 1 Thermoplastic Propane Hose Assembly with 1/4” Male Inverted Flare x QCC Fittings. Fairview's Type 1 Thermoplastic QCC Pigtails are CSA Certified to 350 PSI WP -40°F To 140°F

Applications:
• Used To Conduct Natural Gas In A Gaseous State And Propane In Either A Liquid Or Gaseous State Up To 350 P.S.I
• UL/CSA Approved Type 1 Propane/Nat Gas Assy (Type 1 Assy)

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Hose ID: 1/4”
• Assembly Overall Length: 12” (Tolerance ± 1/4 of an inch)
• Temperature: -40°F to +140°F
• Color: Black
• Max Pressure: 350 PSI
• End: 1/4” Brass Male Inverted Flare
• End: QCC1 ACME
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.30 lbs
