Fairview GAS-FLO™ BV2103-B 1/4" FPT Forged Brass Ball Valve 600 WOG, 150 WSP. Fairview's Forged Brass Ball Valves are full port and CSA, CGA & UL certified

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Features:
• Brass valves for use in W.O.G. = Water, Oil and Gas; W.S.P. = Working Steam Pressure applications
• Two piece Body
• Full Port
• Blowout-Proof Stem
• PTFE Seats
• CSA - ANSI Z21.15/CGA 9.1, ASME B16.44, CGA CR 91-00
• CAN/CGA 3.16, ASME B16.33 & ASME B16.38
• UL 842 (MHKZ): Manual valves-250 psi

Specifications:
• W.O.G: 600
• W.S.P: 150
• Pipe Size: 1/4” FPT
• Connection Type: Female to Female
• Materials: Brass C3700, Chrome & Nickel Plated Steel, PTFE
• Weight: 0.16 lbs

Fairview BV4103-C 3/8" NPTF Forged Brass Ball Valve 600 WOG. Fairview's Forged Brass Ball Valves are full port, feature brass balls and fine NPTF threads

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Features:
• Brass valves for use in W.O.G. = Water, Oil and Gas
• Two piece Body
• Full Port
• Blowout-Proof Stem
• PTFE Seats

Specifications:
• W.O.G: 600
• Pipe Size: 3/8” NPTF
• Connection Type: Female to Female
• Materials: Brass C3700, Nickel Plated Steel, PTFE
• Operating temperature: -40°F to 356°F (-40°C to 180°C)
• Weight: 0.24 lbs

Fairview BV4103-B 1/4" NPTF Forged Brass Ball Valve 600 WOG. Fairview's Forged Brass Ball Valves are full port, feature brass balls and fine NPTF threads

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Features:
• Brass valves for use in W.O.G. = Water, Oil and Gas
• Two piece Body
• Full Port
• Blowout-Proof Stem
• PTFE Seats

Specifications:
• W.O.G: 600
• Pipe Size: 1/4” NPTF
• Connection Type: Female to Female
• Materials: Brass C3700, Nickel Plated Steel, PTFE
• Operating temperature: -40°F to 356°F (-40°C to 180°C)
• Weight: 0.21 lbs

Fairview GAS-FLO™ 3/8” ID x 600” AOL Type 1 Rubber Propane Hose Assembly with 3/8” 45° SAE Female Swivel Flare x 3/8” 45° SAE Female Swivel Flare Fittings. Fairview's Type 1 Rubber F.SAE Assemblies are CSA Certified to 350 PSI WP -60°F To 212°F

Applications:
• Used To Conduct Natural Gas In A Gaseous State And Propane In Either A Liquid Or Gaseous State Up To 350 P.S.I
• UL/CSA Approved Type 1 Propane/Nat Gas Assy (Type 1 Assy)

TECHNICAL DATA SHEET

Specifications:
• Hose ID: 3/8”
• Assembly Overall Length: 600” (Tolerance ±1% of length measured to the nearest 1/8 of an inch)
• Temperature: -60°F to +212°F
• Color: Black
• Max Pressure: 350 PSI
• End: 3/8” Brass 45° SAE Female Swivel Flare
• End: 3/8” Brass 45° SAE Female Swivel Flare
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 7.50 lbs
