General Pump D10076 Quick Disconnect Coupler Plug Stainless Steel 1/4” x 1/4" NPT-F 6,000 PSI

Features:
• Quick disconnect design
• 304 Stainless steel

Specifications:
• Quick Disconnect Coupler: Plug
• Body Material: 304 Stainless steel
• Plug Size: 1/4"
• Thread: 1/4” NPT-F
• Max Temp: 175°
• Max Operating Pressure: 6,000 PSI
• Replaces QCP1FSS
• Weight: 0.06 lb

Fairview 119-CB 3/8 FPT x 1/4 FPT Brass Reducing Coupling. Fairview's Reducing Coupling Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.05 lbs

Fairview 120-CB 3/8 FPT x 1/4 MPT Brass Adapter. Fairview's Adapter Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.05 lbs

Suttner ST-311 Stainless Steel Swivel Coupling 5,000 PSI 3/8 F x 1/4 F. Perfect for hose connection to trigger gum, booms, etc. Prevents hose from tangling or twisting

Features
• High Quality, German engineered components
• Stainless steel material
• Extends the life of your hose
• Double PTFE slide rings for easy movement
• Bearing material: PTFE
• Axial and radial slide bearing

Specifications
• Max Pressure: 5,000 PSI
• Max Flow: 12 GPM
• Max Temp: 300° F.
• Inlet: 3/8" Female NPT
• Outlet: 1/4" Female NPT
• RPM: 30
• Weight: 0.29 lb
