Suttner ST-160M Stainless Steel Single Chemical Injector w/Metering Valve, #4.0, 5000 Psi, 3/8" F x 3/8” M

Features
• Food grade quality and specifications
• Stainless steel construction
• Conserves chemicals
• Locks in position for accurate metering
• Multiple metering positions

Specifications
• Orifice: 4.0
• Max Flow Rate: 21 GPM
• Min Flow Rate: 1 GPM
• Max Pressure: 5,000 PSI
• Min Pressure: 1,000 PSI
• Max Temp: 194° F.
• Inlet: 3/8” Female
• Outlet: 3/8” Male
• Hose Barb: .35” ID hose
• Weight: 1.25 lb

Please use Nozzle Chart to determine proper nozzle size

Note: If between sizes, choose the larger nozzle size

Nozzle Chart

Suttner ST-75 Brass Foam Head 4,000 PSI with #8.0 Air Injector Nozzle and 1/4" F Inlet. The ST-75 produces thick foam for an easy and safe application and to save on chemical usage by reducing splash and drift of chemicals

Features
• By means of the foam head ST-75 different foam applications are possible as the air injector nozzle is easily exchangeable and adaptable
• The flat spray nozzle can be infinitely adapted from the vertical position to the horizontal one
• The maximum flow is dependent on the chosen nozzle size
• By means of the integrated air injector in the foam head the air is sucked in on the face side
• Independent of the length of the lance a constant foam quality is guaranteed
• The spraying result is especially even as a high quality foam nozzle insert is used

ST-75 with ST-160 Chemical Injector on YouTube

Specifications
• Air Injector Nozzle Size: 8.0
• Max Pressure: 4,000 PSI
• Flow Rate: 1 - 6 GPM
• Max Temp: 212° F.
• Inlet: 1/4" Female
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector required and is not included
• Weight: 0.31 lb

Please use Nozzle Chart to determine proper Spray Nozzle Size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Foam Nozzle to use

Foam Nozzle Chart

MTM Hydro's Brass Nozzle Cleaner feature a 1/4" QC plug for easy storage and a 0.8mm diameter cleaning pin for even the smallest nozzles. Keep your nozzles in top condition by regularly cleaning them to ensure optimum pressure and GPM

Specifications:
• Body & Cap Material: Brass
• Pin Size: 0.8MM (3.0 Nozzle size or greater)
• QC Plug: 1/4”
• Weight: 0.10 lbs

Suttner ST-1500 SS LFT Stainless Steel Spray Gun 5,000 PSI. Industry standard, the ST-1500 is well-suited for a variety of industrial pressure washing applications

Features
• High Quality, German engineered components
• LFT "Low Friction Trigger, reduces pulling force
• Designed to be “universally” comfortable, even for small hands
• Stainless steel spring, needle, ball and seat
• Stainless steel inlet connection, including inlet pipe
• Stainless steel outlet
• Forged brass valve housing for maximum strength
• Unitized valve for easy repair
• Fully rebuildable

Specifications
• Max Pressure: 5,000 PSI
• Max Flow: 10.4 GPM
• Max Temp: 300° F.
• Inlet: 3/8" Female NPT
• Outlet: 1/4" Female NPT
• Weight: 1.24 lb
