Features
• Increases cleaning efficiency as much as 200%
• The 0° rotation creates a cleaning and tearing action
• Ideal for hard surfaces
• Improved materials for longer life

Specifications
• Nozzle Size # 4.0
• Max PSI: 5,070
• Max Temp.: 212° F
• Inlet: 1/4" Female NPT
• NOTE: All rotating nozzles should be started pointing downward
• Weight: 0.90 lbs

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General Pump 0° x #3.0 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 0°
• Nozzle Size: 3.0
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Twist Coupler Socket, 3/8" FPT x M22-14MM F Brass 4,000 PSI.

Features:
• Secure twist connection
• Precision machined
• High-Impact plastic Knob
• Internal o-ring seal

Specifications:
• Max. Pressure: 4,000 PSI
• Max. Flow: 10.0 GPM
• Material: Brass & Zinc plated steel
• Outlet: Female M22-14MM F
• Inlet: 3/8” FPT

Mecline 0° High Pressure Threaded Spray Nozzle with Ceramic Orifice and 1/4” Male NPT

Features
• Ceramic inserts provide up to 10 times the wear life of stainless steel inserts
• Ceramic insert is resistant to wear
• The ceramic insert guarantees a more precise and stronger stream
• Stainless Steel AISI303 body

Specifications
• Flat fan jet angle: 0°
• Nozzle Size: 3.0
• Rated Pressure: 4,500 PSI
• Permissible Pressure: 5,075 PSI
• Rated Temperature: 300° F
• Inlet: 1/4” Male NPT
• Weight: 0.63 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart
