The AR North America CL Series electric clutch enables operation of the drive system for your pump without the pump itself being engaged. There can be significant reduction in wear and tear on the pump since it is only operating when called for

Specifications
• Electric clutch for AR XM, RK & XW series pumps
• 12 Volt single groove clutch
• Size: 24mm
• Works with "A" section belts
• Use with AR-CLMP clutch mounting plate below
• Replaces CL-521491

Features:
• Special thick solid ceramic plungers for long life and durability
• Oversized tapered roller bearings and the precision supports assure proper shaft alignment and maximum life.
• Precision cast cooling fins are anodized for maximum heat dissipation
• Nickel plated, forged brass head
• One-Piece connecting rods are oversized for strength and load disbursement
• Valve cages of special designed Ultra-Form provide positive seating and extended life

Specifications:
• Max. Volume: 4.0 GPM
• Max. Discharge Pressure: 4,000 PSI
• Max. Pump Speed: 1,750 RPM
• Shaft Diameter: 24mm Solid (long shaft)
• Shaft Length: 2"
• Max. Horsepower Requirements: 14.54 GHP (Industrial Grade)
• Max. Fluid Temp.: 140° F.
• Inlet Ports (2): 1/2" Female
• Outlet Ports (2): 3/8" Female
• Oil capacity: 15.0 oz
• Weight: 20.0 lb.
