Delavan 7870-101Y-SB PowerFLO™ FB2 Series 7.0 GPM 100 PSI Diaphragm Pump with 1/2” FNPT Ports. Demand Switch – Operates only when liquid flow is required.

Features:
• The FB2 pumps are heavy duty 12V, 7 GPM pumps with Santoprene diaphragms and Santoprene valves
• These FB2 5 chamber pumps are smooth running, and can run dry, and self-prime
• The pumps feature popular threaded NPTF ports, along with a heavy duty demand system to turn the pump off when not in use, saving pump life and saving energy
• The FB2 pumps are known for one of the highest flow rates in the 12V market
• The FB2 pumps are used in difficult applications such as roof cleaning, and de-icing
• Certified to NSF/ANSI Standard 61 & 372
• Made in the USA
• 100% Factory tested
• 2 Year warranty from date of purchase

Motor:
• Type: 12 VDC permanent magnet, totally enclosed, non-ventilated
• Leads: 12 AWG, 12” long
• Max Amps (100 PSI): 25
• Duty Cycle: See Heat Rise graph

Materials of Construction:
• Motor Shell: Coated Steel
• Housing: Polypropylene Glass Filled
• Valves: Santoprene
• Diaphragm: Santoprene
• Fasteners: Stainless Steel

NSF/ANSI Certified:
• NSF/ANSI Standard 61 - Drinking Water System Components - Health Effects
• NSF/ANSI 372 and conforms with the lead content requirements for “lead free” plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act

Pump:
• Demand Switch – Operates only when liquid flow is required
• Type: 5-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 140° F Max.
• Priming Capabilities: 14’
• Max. Flow: 7.0 GPM
• Pressure Shut-Off: 100 PSI
• Inlet/Outlet Ports: 1/2” FNPT
• Packaging: Small box
• Weight: 9.75 lbs

Everflo EF1000 Diaphragm Pump. Demand Switch – Operates only when liquid flow is required. Replacement for agricultural sprayers and fluid transfer applications.

Features:
• Polypropylene pump housing and valve plate
• Viton® Valves – Santoprene® Diaphragm
• Zinc Plated Steel fasteners
• Polypropylene 2” Motor Shelll
• Honeywell™ Micro Switch
• Round-Up® Ready
• Self Priming up to 4’ above fluid level

Specifications:
• Demand Switch – Operates only when liquid flow is required
• Max. Flow: 1.0 GPM
• Max. Pressure: 40 PSI
• Max. Fluid Temperature: 140° F
• Voltage: 12 VDC
• Max. Amps: 4.0
• Inlet/Outlet Ports: 3/8” Hose barb
• Inline fuse protection
• Wire leads with 2-pin connector
• Owner’s manual and colored box
• CE Approved*
• Pump Dry Weight: 1.3 lbs

PA RB 65 Red Adjustable Spray Wash Down Gun with Inlet Swivel for Food Industry. RB65 suitable for use up to 350 PSI and 16 GPM. Shockproof gun with adjustable conical/pencil jet and Stainless Steel Piston

Features
• Low pressure washdown gun with conical/pencil jet controlled by the trigger
• Adjustable screw to vary cone width from 0° to 60°
• Covered by semi-housings of non-stainable shockproof plastic, entirely sealed and with 3 rubber protective rings.
• Plastic trigger protected by hand guard
• Minimum fatigue for trigger opening and use
• Internal structure in brass and Sst
• Ergonomic construction
• Inlet swivel connection

Specifications Sheet

Specifications
• Rated Pressure: 350 PSI
• Rated Flow Rate: 16.0 GPM
• Rated Temp: 195° F.
• Max Temp Continuous Use: 140° F.
• Casing Color: Red
• Seals Material: Viton
• Piston Material: aisi303 Sst
• Swivel Inlet: 1/2" Bsp F
• GP #: YG1635SR
• Weight: 37.39 oz

Everflo EF788690 Pressure Switch Assembly 3–7 GPM Pumps

Specifications:
• Everflo Pump Models: EF3000, EF3000-QA, EF4000, EF4000-QA, EF5500, EF5500-QA, EF7000 & EF7000-QA
• Replaces EF787366
• Weight: 0.10 lbs
