PLUNGER KIT VRX (3 PLUNGERS)

Replaces Comet # 5026.0260.00

PA Pulsar 4 Unloader Plumbing Kit for Pressure Washer Pump with Safety Relief and EZ Start– 4,050 PSI Max. This unloader kit has all the components to make installation easy

Specifications:
• Works with pumps that have 1/2” FPT inlet and 3/8” FPT Outlet
• Safety relief vale protects equipment and people with adjustable “Pop Off” protection
• Built-In easy start valve relieves back pressure during engine start up
• Maximum Pressure: 4,050 PSI
• Max. Volume: 10.5 GPM

COMPONENT:
• PA Pulsar 4 Adjustable Unloader Valve 4,050 PSI with EZ Start
• GP Safety pressure relief valve with adjustable range: 1,000 - 6,000 PSI
• 3/8” Steel street elbow
• 24” of push-on bypass hose
• 1/4” Male push on fitting
• 3/8” Male push-on fitting
• 3/8M x 3/8M Hex Nipple Steel
• GP Thermal relief valve protects pump from overheating
• GP Duraview water inlet filter with garden hose connection
• 3/8” QC socket
• 3/8” QC plug
• Roll of Teflon tape
• Note: Pump in 2nd picture is not included and kit may look different than shown in picture
• Unloader Must Be Installed Vertically For Proper Operation
• Weight: 5 lb

New Design Features:
• Interior Design – more efficient flow and operation
• Dual Locking Nuts – vibration resistant for setting maximum pressures
• New Spring Material – more resistant to fatigue, powder paint resists rusting
• Piston – large diameter, more strength and contact area for shifting alignment
• Discharge Nipple – sealing o-ring has been moved to the lower part of the thread, increases hydro strength and fitting strength
• Shutter Valve – hex design, less contact area for smooth shifting (prevents binding). larger size, longer life and more positive shifting

Featuring:
• Over sized handle – easier adjustment
• Forged valve body – excellent strength
• Two inlet ports
• Two by-pass ports
• Ultra thick inlet and discharge ports - added strength
• Color coded springs and caps – easy valve identification
• All ports are FNPT

Specifications:
• Spring Color: Black:
• Replaces AL607 & AL607X
• Maximum Pressure: 4,495 PSI
• Max. Volume: 8.0 GPM
• Adjustable pressure
• Brass valve body
• Max. Fluid Temp.: 194° F.
• Inlet Ports (2): 3/8" FNPT
• Discharge Ports (1): 3/8” FNPT
• Bypass Ports (2): 3/8” FNPT
• Weight: 29.6 oz

Comet ZWD4040G Industrial Duty Pump. This ZWD 4040G 4,000 PSI & 4.0 GPM pump is designed to direct drive on gasoline 1” Hollow Shaft engines ranging from 9 - 13 HP

Features
• Reversible Crankshaft for Easy Right or Left Hand Mounting
• Increased Fin Depth Increases Surface Area to Maximize Heat Dissipation
• Stainless Steel Unitized Check Valves
• Heat-Resistant Solid Ceramic Plungers Operating on Lubricated Packings
• Direct Drive Gas Engine Mounting Flange (SAE J609B)
• Reinforced Crankcase for Increased Load Capacity
• Enlarged Crankcase Increases Oil Capacity for Better Lubrication and Lower Operating Temperatures
• One-Piece Industrial-Grade Oversized Bronze Connecting Rods

WARNING: High Pressure Systems require a primary pressure regulating device (i.e. regulator, unloader) and a secondary pressure relief device (i.e. pop-off valve, relief valve). Failure to install such relief devices properly could result in personal injury or damage to pump or property. We do not assume any liability or responsibility for the operation of the user’s high pressure system.

Specifications
• Max. Volume: 4.0 GPM
• Max. Discharge Pressure: 4,000 PSI
• Max. Pump Speed: 3,400 RPM
• Shaft Diameter: 1” Hollow
• Max. Horsepower Requirements: 14.5 GHP
• Inlet Port: 1/2" FPT
• Outlet Port: 3/8" FPT
• Oil capacity: 14 oz
• Replaces Comet # 6305.0900.00
• Note: Item for sale is PUMP ONLY as shown in picture and does not include unloader which is required for proper operation
• Weight: 17.5 lb.
