PA PR5 / General Pump YPRESSWITCH521 5,000 PSI Pressure Switch with 220 PSI (Blue) activation and 1/4 Bsp M brass inlet. Electro-mechanical device, which, upon reaching a pre-set pressure (220 PSI) , opens or closes an electrical control contact

Specifications
• Activation (Blue) PSI: 220
• Max. Voltage: 250
• Permissible Pressure: 5,000 PSI
• Rated Temp: 165° F
• Max. Curr. Strength: 6 (A) – resistive load - 2 (A) – inductive load
• Electrical insulation: 55 IP
• Connection Material: Brass
• Cable Length: 39.4" (1000 mm)
• Electric Wire: 3 x 0.75 mm2
• Inlet: 1/4 Bsp M
• Weight: 4.83 oz.

General Pump #3.0 Quick Connect (Q) Spray Nozzle 5-Pack

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Nozzle Size: 3.0
• Contents: One each of a 0º, 15º, 25º, 40º and 65º #40 soap nozzle
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.50 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Gereral Pump YVB135KDM Direct Mount Unloader Fits General Series Pumps: TT & TP 51 Series Pumps

• Maximum Pressure: 3,650 PSI
• Max. Volume: 6.5 GPM
• Adjustable pressure
• No Chemical Injector
• Forged brass body & hardware
• Built-In bypass channel
• Max. Fluid Temp.: 195 degrees F.
• Inlet Port: 3/8" FPT
• Outel Port: 3/8” MPT
• Weight: 1.5 lbs
