Comet Oil Seal Kit AXD

Replace Comet # 5019.0079.00

Comet Check Valve Kit AXD, AXS & GXD

Replaces Comet # 5025.0014.00

Comet AXD 2524G-T, AXD2524GT Commercial Duty Radial-Axial Pump with adjustable unloader & chemical injection

Features:
• Direct Drive with Gas Flange 4-7 HP SAE (2-9/16 center to center)
• Built-In uniflow unloader with chemical injector standard
• Max. Volume: 2.4 GPM
• Max. Discharge Pressure: 2,400 PSI
• Fits most horizontal engines with a 3/4” straight solid shaft with keyway

Specifications:
• Max. Pump Speed: 3400 RPM
• Shaft Diameter: 3/4” Hollow
• Max. Horsepower Requirements: 5.45 GHP
• Max. Fluid Temp.: 145 degrees F.
• Inlet Ports (1): 3/4" GH (garden hose)
• Discharge Ports (1): 3/8" MPT
• Auxiliary Port: 3/8" Female
• Forged brass head
• Stainless steel plungers
• Replaces Comet # 6501.0050.00
• Weight: 13.0 lb.

Comet Water Seal Kit AXD, Replaces 5019.0077.00 & 5019.0078.00
