• Kuriyama Tigerflex® WT200X50 PVC Hose
• Series WT Heavy Duty PVC Food Grade Material Handling Hose
Features:
• Clear PVC construction
• Complies with all applicable FDA and USDA requirements
• Complies with 3-A sanitary standards
• Allows visual confirmation that material is flowing
• Smooth bore construction - eliminates material build-up
• Convoluted cover design - provides increased flexibility
Applications:
• Pneumatic conveying systems for powder, pellets or granular materials
• Food transfer systems
• Poultry cleaning operations
Specifications:
• Service Temp. Range: -4º F to 150º F
• Nominal ID: 2”
• Nominal OD: 2.40”
• Length: 50’
• Working Pressure 68°F: 40 PSI
• Working Pressure 104°F: 20 PSI
• Vacuum Rating 68°F: 28 HG
• Vacuum Rating 104°F: 24 HG
• Min. Bend Radius 68°F: 4”
• Weight: 28.0 lbs.
