Features:
• Wire helix reinforcement prevents kinking or collapsing
• Hose diameter will not expand under normal rated working pressures
• 29.9" HG vacuum rating @ 70º F
• Electrogalvanized helical steel wire can be used for static dissipation
• Yarn reinforcement provides higher working pressure
• Crystal clear - allows visual confirmation of product flow
• Glass-smooth interior - reduces material buildup
• Inner material is NSF certified for food applications (NSF-51 & NSF-61)
• Inner material also meets FDA, USDA and 3A criteria
• Resistant to chemicals
• Self-extinguishing
• Non-marking
• Non-toxic
• Silicone-free

Applications:
• Pressure and vacuum applications which require excellent kink resistance
• Ideal for applications which require the hose to withstand both high vacuum and pressure
• Water transfer
• Liquid food transfer

Specifications:
• Service Temp. Range: +15º F to 150º F
• Nominal ID: 1-1/2”
• Nominal OD: 2.030” (subject to change)
• Length: 50’
• Working Pressure @ 70º F: 175 PSI
• Min. Bend Radius @ 70º F: 5-1/2”
• Weight: 43.0 lbs.
