Features
• Forward jet breaks up clogs & debris
• 3 Backward jets drive nozzle forward and flushes and removes debris from sides of line
• Corrosion resistant stainless steel construction

Specifications
• Inlet: 1/4” FPT
• Nozzle Size: # 4.5
• Material: Stainless steel
• Maximum Pressure: 4,200 PSI
• Max. Fluid Temperature: 300º F
• Weight: 0.6 oz.

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Features:
• Suitable for cold and hot water commercial pressure cleaning applications
• Reinforcement: One layer of high tensile braided steel – R1 Rating
• Cover: Wrapped finish with embossed lay line in grey “mark-less” cover color
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 4’
• Working (Maximum): Up to 4,000 PSI
• Burst (Minimum): 12,000 PSI
• Color: Grey, “mark-less”
• Maximum Temperature: 250° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Weight 1.25 lbs

4,000 PSI 4.0 GPM General EZ4040G Direct Drive Pump Made Ready W/ PULSAR4KHPEZ EZ Start Unloader. Pump is ready to use right out of the box

PUMP:
• General EZ4040G Pump with SAE J609 Gas Flange
• Direct Drive with Gas Flange 9.0-13.0 HP SAE
• Max. Volume: 4.0 GPM
• Max. Discharge Pressure: 4,000 PSI
• Max. Pump Speed: 3,400 RPM
• Shaft Diameter: 1” Hollow
• Max. Horsepower Requirements: 14.5 GHP
• Max. Fluid Temp.: 165º F
• Forged brass head & valve covers
• Solid ceramic plungers

COMPONENTS:
• General EZ4040G Triplex Plunger Pump
• PULSAR4KHPEZ EZ Start Unloader 4,050 PSI, 10 GPM
• Thermal relief valve
• 3/8” Hose Barb and Clamp Keeps Hose Secure and Sealed
• 3/4” Garden Hose Inlet Fitting with 1/4” Side Port
• 3/8” QC brass socket Installed and 3/8” QC Plug Included
• Mounting bolts
• Note: Pumps are not tested prior to shipping and unloader will need to be adjusted
• Weight: 23.50 lb
