Spraying Systems 0º Brass H-U 1/4" (M) VeeJet® Spray Nozzle. As the liquid exits through the sharp V shape cut of the orifice, it forms into a flat spray pattern. The distribution is tapered from the center of the spray

Features
• Flat fan type, tapered edge spray pattern
• Consistent performance over the industry's largest range of flow rates and pressures
• One-piece design
• Uniform spray distribution with flow rates from .012 to 1237 gpm
• Operating pressures up to 500 psi

TECHNICAL DATA SHEET

Specifications
• Spray Angle: 0º
• Capacity Size: 30
• Operating Pressure: Up to 500 PSI
• Material: Brass
• Inlet Connection: 1/4" Male thread
• Length: 1.0”
• Hex: 9/16”
• Net Weight: 0.8 Oz

General Pump 25° x #2.5 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 25°
• Nozzle Size: 2.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• BE # 85.225.025
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Features:
• High Quality, German engineered components
• Comfort technology designed molded grip conforms to the curvature of the hand, allowing to comfortably change positions and work longer hours
• Linear aeration provides continuous air flow between hand and exclusive Suttner "star-shaped" grip
• Grip is directly molded on to lance providing protection and strength
• Threads are rolled on providing consistent sealing and four times the strength than cut threads

Specifications:
• Length: 36"
• Pipe Material: Nickel chrome plated steel
• Grip: 11" Molded "star-shaped"
• Inlet: 1/4” MNPT
• Outlet: 1/4” MNPT
• Maximum Pressure: 6,000 PSI
• Max. Temp.: 300° F
• Weight: 1.28 lbs.

Medium Duty 4,000 PSI Pressure Washer Trigger Gun and Lance Kit. Includes all the components necessary to assemble the wand

Kit Components:
• AR 5101 Medium-Duty 4,000 PSI trigger gun
• Suttner ST-007 36” Nickel Plated Molded Grip Lance 6,000 PS
• General Pump brass 5,000 PSI quick coupler socket
• General Pump zinc plated 4,000 PSI steel quick coupler plug
• Teflon Tape: 1 Roll

Specifications:
• Max Pressure: 4,000 PSI
• Max Flow: 7.0 GPM
• Max Temperature: 300° F
• Trigger Gun Inlet: 3/8" Male QC plug
• Lance Outlet: 1/4" Female QC socket (accepts QC color coded nozzles)
• Note: Assembly is required
• Weight: 3.10 lbs
