Fairview QD-GMRVC4-4F GAS-FLO™ 1/4” Ball Vale Coupler x 1/4” FPT CSA RV Gas Quick Disconnect. Fairview's Recreational Vehicle Valved Gas QD’s are CSA Certified up to 60 PSI WP

Features:
• C.S.A. (C.G.A. / A.G.A.) design certified for natural gas and L.P. gas - air mixtures
• For quick connect and disconnect of LP gas hose to camper/RV cooking stoves

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Coupler (Body Size): 1/4
• Female Pipe Thread: 1/4
• Material: Brass
• Weight: 4.2 oz

Fairview 120-DB 1/2 FPT x 1/4 MPT Brass Adapter. Fairview's Adapter Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.08 lbs

Fairview GAS-FLO™ 1/4” ID x 48” AOL Type 1 Thermoplastic Propane Hose Assembly with 1/4” Male Pipe x RV QD Nipple Fittings. Fairview's Type 1 Thermoplastic RVQD Extension Assemblies are CSA Certified to 350 PSI WP -40°F To 140°F

Applications:
• Used To Conduct Natural Gas In A Gaseous State And Propane In Either A Liquid Or Gaseous State Up To 350 P.S.I
• UL/CSA Approved Type 1 Propane/Nat Gas Assy (Type 1 Assy)

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Hose ID: 1/4”
• Assembly Overall Length: 48” (Tolerance ±1% of length measured to the nearest 1/8 of an inch)
• Temperature: -40°F to +140°F
• Color: Black
• Max Pressure: 350 PSI
• End: 1/4” Brass Male Pipe
• End: 1/4” Brass RV QD Nipple
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.40 lbs

Fairview QD-GMRVN4-4M GAS-FLO™ 1/4” Nipple x 1/4” MPT CSA RV Gas Quick Disconnect. Fairview's Recreational Vehicle Gas QDs are CSA Certied up to 60 PSI WP

Features:
• C.S.A. (C.G.A. / A.G.A.) design certified for natural gas and L.P. gas - air mixtures
• Full flow plug for quick connect and disconnect of R.V. style coupler

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Nipple (Body Size): 1/4
• Male Pipe Thread: 1/4
• Material: Brass
• Weight: 1.0 oz
