Kuriyama BEGP-038X700 3/8” Black EPDM Rubber Hose 250 PSI

Applications:
• Agricultural
• Construction
• Industrial
• Water service lines

Construction::
• Cover – Black abrasion and ozone resistant EPDM, limited oil resistance
• Reinforcement – Spiral polyester yarn
• Tube – Black EPDM, limited oil resistance
• Made In USA

Specifications:
• Color: Black
• Nominal ID: 3/8”
• Nominal OD: 11/16”
• Working Pressure: 250 PSI
• Service Temperature [Min]: -40º F
• Service Temperature [Max]: 200º F
• Brand: Redi-GP™
• Type: Air and Water Hose
• Material: EPDM Rubber
• Length: 1’
• Weight: 0.16 lbs/ft

Fairview 195-6 3/8 Hose ID x 3/4 Swivel FGH Brass Hose Barb Fitting. Fairview's Female Hose Barb Connector Water Hose Fittings are Made with Solid Industrial Quality Bras

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Applications:
• Brass hose barbs are recommended for general purpose air, water and other low pressure applications
• CA360 brass construction prevents rust and corrosion

Specifications:
• Working Temperature: -40°F to +220°F, -40°C to +104°C
• All hose barbs must be firmly fastened with hose clamps or ferrules
• Weight: 0.12 lbs

5/16" Stainless Steel Worm Gear Hose Clamp Size 05 - 1/4" to 11/16"

Specifications:
• Size: 05
• Min. Clamp Dia.: 1/4”
• Max. Clamp Dia.: 11/16”
• Band Width: 5/16”
• Band, Housing & Screw: Series 300 Stainless Steel
• Weight: 0.2 oz

General Pump D10090 Quick Disconnect Coupler Socket Stainless Steel 1/2” x 1/2" NPT-F 5,000 PSI

Features:
• Quick disconnect design
• 304 Stainless steel
• EPDM O-Ring

Specifications:
• Quick Disconnect Coupler: Socket
• Body Material: 304 Stainless steel
• Socket Size: 1/2"
• Thread: 1/2” NPT-F
• Max Temp: 175°
• Max Operating Pressure: 5,000 PSI
• Replaces QCS3FSS
• Weight: 0.35 lb
